ZPT-265 Rotary Single-discharging High Speed Tablet Press-Dr.Pharm

The 265 series tablet press is a rotary single-discharging high speed tablet press, which can convert materials from granules/powder to tablets and press ordinary circular tablets, large tablets, shaped tablets, special shaped tablets, single and double sided lettering tablets and cartoon tablets and is suitable for wet and dry granulation and tablet pressing of TCM granules in the medicine, health care products, electronics, food and chemical industry.

Diversified feeder, single impeller/ double impeller / flower basket

Select according to powder characteristics

With/without hand wheel operation, stepper/servo motor configuration

Free choice by the customer as needed

Central lubrication system

Precise control of oil level at each point position

Mechanical pressure support

Prevent oil leakage pollution

Double pressure forming

Better tablet molding effect

Mirror treatment on the middle turret surface

Better solve the problem of powder dumping

l Lower punch damping

l Better loading precision and reduced vibration

l Pressure overload protection

Better protection for equipment and personal installation

Model Parameter	ZPT - 16	ZPT - 23	ZPT - 30
Number of punches	16	23	30
Mold model	D	B	BB
Output range (tablet/hour)	21000 - 105000	30000 - 151000	39000 - 198000
Speed range (RPM)	22 - 110
Maximum main pressure force (kN)	100
Maximum prepressure force (kN)	20
Max filling depth	20mm
Tablet thickness range	0.5 - 8.5mm
Max Tablet Diameter	Φ25mm	Φ16mm	Φ13mm
Max long axis of shaped tablet	<25mm	<19mm	≤16mm
Middle diameter	Φ38.10mm	Φ30.16mm	Φ24.00mm
Punch diameter	Φ25.35mm	Φ19.00mm	Φ19.00mm
Punch length	133.60mm
No - load noise	≤78dB
Main motor power	5.5kW
Equipment dimensions	700×1000×1750 mm
Net weight of equipment	1300kg
Remarks	Capacity: The actual production speed of the equipment is related to the actual conditions of tablet pressing, such as the conditions of powder (fluidity, compressibility, uniformity of powder density), the shape and size of the produced tablet, and the pressing force. Mold use: For the same powder, the larger the tablet, the greater the pressing force required during production, resulting in the greater the friction between the punch and the guide rail, the greater the vibration of the equipment, and the greater the wear of the punch, guide rail and press wheel. Therefore, in the production of tablets, the service life of the mold shall also be considered while pursuing yield.
